C
SERIES
STEEL: HAND & MOTOR DRIVEN C SERIES

HYDRAULIC DRIVE REELS

APPLICATION
Simple, heavy duty hydraulic motor driven
models for a wide range of appliations.
Supplied with a high quality hydraulic CUSTOM COLOUR OPTIONS AVAILABLE
motor for effortless operation.

HOSE TYPE Supplied with or without
hose
MEDIA As per your hose type

CONSTRUCTION Carbon Steel (standard)
MATERIALS 304 Stainless Steel
H19480300
316 Stainless Steel SHOWN WITH ROLLER GUIDE AND
Aluminium FEATURES GEAR GUARD RIGHT HAND REEL
FINISH Powder Coated S ?
Galvanized AU ST RA LI HEAVY DUTY MOTOR MOTO CUSTOM
AUSTRALIANAN
MADE STEEL DRIVEN OPTIONS

OPTIONAL EXTRAS 4 way roller guides
Gear guard C SERIES HYDRAULIC MOTOR DRIVEN
Friction brake
Extra heavy duty
wrap spreaders* Model Hose ID Capacity (mm) Hose Capacity (m) Max PSI Overall Width (G)
Wall mount swivel
bracket H6480150 6 60 5000 370
Standard construction material is carbon steel. H6480300 6 140 5000 520
*Note: we recommend heavy duty wrap spreaders H6480450 6 240 5000 670
for pressures above 2000 psi.
H6480600 6 300 5000 820
H10480150 10 40 5000 370
H10480300 10 100 5000 520
H10480450 10 145 5000 670
DIMENSIONS H10480600 10 200 5000 820
H12480150 12 30 5000 370
H 6 480 150
H12480300 12 60 5000 520
{
Series Hose ID Overall Wrap H12480450 12 100 5000 670
{
{
{
(mm) depth (B) width (F)
H12480600 12 130 5000 820
H19480150 19 15 5000 370
H19480300 19 30 5000 520
A = 550mm H19480450 19 40 5000 670
820
19
H19480600
5000
60
520
H25480300
20
25
3000
H25480450 25 30 3000 670
F +50mm H25480600 25 45 3000 820
G 480
B H38640350* 32 - 38 20 1500 640
Detailed dimensional drawings available on request.
Quote drawing number ST11093-A.1 *CH Series Dimensions:
A = 680mm, B = 560mm, F = 350mm, G = 640mm
= Quick Ship Item, see inside back cover for
more information.
