Page 38 - Recoila Hose and Cord Reels Catalogue - 23rd Edition

T
SERIES
STEEL: HAND & MOTOR DRIVEN STANDARD Pin lock T SERIES 4AM PNEUMATIC MOTOR DRIVEN depth(B)

25mm ID HOSE CAPACITY
Hose
Overall
Catalogue
Frame
Overall
width (G)
height (H)
length
code
660
AT25580150
385
10
675
660
435
AT25580200
18
675
FEATURES
Top rollers
635
675
30
AT25580400
660
OPTIONAL
Bottom rollers
35
EXTRAS 800psi swivel AT25580300 25 535 675 660
660
675
685
AT25580450
Friction brake
1500psi swivel AT25580500 40 735 675 660
4000psi swivel AT25580550 45 785 675 660
Gear guard AT25580600 55 835 675 660
Reduction drive
Auxiliary bevel crank AT25580650 60 885 675 660
Level layer rewind* AT25640500 65 735 690 700
Choice of finish AT25640550 70 785 690 700
AT25640600 80 835 690 700
* Wrap diameter for the above models = 280mm OD
T SERIES 6AM PNEUMATIC MOTOR DRIVEN
32-38mm ID HOSE CAPACITY Catalogue Hose Overall Frame Overall
code length width (G) height (H) depth(B)
AT38640300 15 592 690 700
STANDARD Pin lock
FEATURES Top rollers AT38640400 20 692 690 700
800psi swivel AT38640500 30 792 690 700
OPTIONAL Bottom rollers AT38640600 35 892 690 700
EXTRAS Friction brake AT38640700 40 992 690 700
1500psi swivel AT38780300 25 592 830 800
4000psi swivel AT38780400 35 692 830 800
Gear guard AT38780500 45 792 830 800
Reduction drive AT38780600 60 892 830 800
Auxiliary bevel crank
Level layer rewind* * Wrap diameter for the above models = 410mm OD
Choice of finish
T SERIES 6AM PNEUMATIC MOTOR DRIVEN
50mm ID HOSE CAPACITY Catalogue Hose Overall Frame Overall
code length width (G) height (H) depth(B)
AT50640300 5 592 690 700
STANDARD Pin lock
FEATURES Top rollers AT50640400 8 692 690 700
800psi swivel AT50640500 10 792 690 700
OPTIONAL Bottom rollers AT50640600 12 892 690 700
EXTRAS Friction brake AT50640700 15 992 690 700
1500psi swivel AT50780300 10 592 830 800
3000psi swivel AT50780400 20 692 830 800
Gear guard AT50780500 25 792 830 800
Reduction drive AT50780600 30 892 830 800
Auxiliary bevel crank
Level layer rewind* * Wrap diameter for the above models = 410mm OD
Choice of finish

*Level layer rewind system not available on all models. Please consult the factory.
