POLY: SPRING REWIND OL SERIES
SERIES
OIL HOSE REELS
APPLICATION
ReCoila GEN III OL Series reels are the ideal
solution for light duty oil transfer.
HOSE TYPE Rubber. Complies with
ISO1436, DNV, ABS,
GL, BV, NKK, RINA,
MSHA2
MEDIA Oil
MINIMUM TEMP -30°C
MAXIMUM TEMP 90°C FEATURES
MAX PSI 1200* P 2
LIMITED SPRING
FITTING TYPE BSP** AUSTRALIANAN ENGINEERED YEARS
LI
RA
ST
AU
POLYPROPYLENE
MADE
COMPOSITE
WARRANTY REWIND
WEIGHT 12kg
*Maximum hose pressure rating is based at an DIMENSIONS
operating temperature of 30°C.
559mm
**NPT, JIC, JIS and Metric threads are available
on request.
490mm
239mm
OL SERIES
Model Hose ID Hose Length Inlet Fitting Outlet Fitting
OL1015 10mm 15m 3/8” BSPF 3/8” BSPM
OL1210 12mm 10m 1/2” BSPF 1/2” BSPM
= Quick Ship Item, see inside back cover for more information.
