1700
SERIES

OPTIONAL OPTIONAL
P/NO. 1703 P/NO. 1708

THIS OPTIONAL IS SUPPLIED UNASSEMBLED SWIVELLING ARM For installation with middle
FIXED BRACKET For wall, floor or ceiling travel feeding. Installation methods 3,4 at page
fastening (standard configuration is for 141. Impossible to install the swivelling arm with
side fastening). Check on the table at other optionals. Check on the table at pages
pages 142 the models on which the optional 142 the models on which the optional arm can
bracket can be installed. be installed. It is possible to install this optional
only during the assembly of the cable reel, so
this part cannot be bought separately.
CAUTION: It is NOT possible to install the
ratchet on reels with swivelling
arm art. 1704 - 1708

CABLE REELS

P/NO. 1704 P/NO. 1708

REEL INSTALLATION METHODS
1 2
Stationary application

Manual use Cable reel on mobile application
3 4
Stationary Stationary
application application
Poste fixe

Cable reel on mobile application, 2 directions uncoiling Cable reel on mobile application, 2 directions uncoiling
5 Mobile 7 8
application
Poste mobile

Mobile
Cable reel on stationary application application
6 Mobile
application
Poste mobile Mobile
application

Cable reel on stationary application Vertical uncoiling Vertical uncoiling

◄ CONTINUED FROM PREVIOUS PAGE CONTINUED OVERLEAF ►
