HW
SERIES
POLY: SPRING REWIND HW SERIES

HOT WATER REELS

APPLICATION

Specially designed for hot water wash
down applications in kitchens and food
prep areas.

Perfect for use in food processing areas -
the vented case design allows the reel to
be hygenically cleaned as required and
allows for adequate air flow.
Available with or without a heavy duty,
fully insulated washdown gun. FEATURES

For accessories, guns and nozzles, see P
2
page 138. AUSTRALIANSTRALIAN ENGINEERED YEARS
LIMITED SPRING
AU
MADE COMPOSITE WARRANTY REWIND
POLYPROPYLENE

HOSE TYPE Nitrile blended PVC
MEDIA Hot water DIMENSIONS
MINIMUM TEMP -30°C 559mm
MAXIMUM TEMP 85°C
MAX PSI 225*

FITTING TYPE BSP**
WEIGHT 12kg*** 490mm

Standard swivel configuration is brass; 316 stainless
steel is available as an optional extra.
239mm
*Maximum working pressure of the hose is rated at
225psi @ 23°C, operating temperature 85°C @ 120psi.
**NPT, JIC, JIS and Metric threads are available on
request.
***HW1015 weighs 11kg.

HW SERIES
Model Hose ID Hose Length Max PSI Inlet Fitting Outlet Fitting
HW1015 10mm 15m 240 3/8” BSPF 3/8” BSPM
HW1020 10mm 20m 240 3/8” BSPF 3/8” BSPM
HW1215 12mm 15m 240 1/2” BSPF 1/2” BSPM
HWG1015 10mm 15m 240 3/8” BSPF Heavy Duty Washdown Gun
HWG1020 10mm 20m 240 3/8” BSPF Heavy Duty Washdown Gun
HWG1215 12mm 15m 240 1/2” BSPF Heavy Duty Washdown Gun
= Quick Ship Item, see inside back cover for more information.
